DS-YTG 1T 2T 3T 5T 10T Low Level Hand Chain Hoist Trolley, 1000kg 2000kg 3000kg 5000kg 10000kg Low Headroom Hoist Trolley
- Dawson Group Ltd. - China Manufacturer, Supplier, Factory
| Model | DS-YTG-010 | DS-YTG-020 | DS-YTG-030 | DS-YTG-050 | DS-YTG-10 | |
| Rated weight (kg) | 1000 | 2000 | 3000 | 5000 | 10000 | |
| Standard Lifting Height (m) | 3 | 3 | 3 | 3 | 3 | |
| Full Load When the Pull Force | 305 | 340 | 350 | 370 | 380 | |
| Test Load (N) | 1250 | 2500 | 3750 | 6250 | 12500 | |
| Lifting Chain Diameter × Number of Rows (mm) | 5*15 | 6*18 | 8*24 | 10*30 | 10*30 | |
| Hand Chain Zipper Diameter (mm) | 5*15 | 5*15 | 5*15 | 5*15 | 5*15 | |
| Pack Size(cm) | 44*36*33 | 51*39*36 | 60*45*44 | 67*53*54 | 85*80*54 | |
| Lifting Chain Lifting Height for Each Additional Weight of 1m (kg/m) | 1.08 | 1.54 | 2.72 | 4.4 | 8.8 | |
| Minimum Clearance Hmin (mm) | 166 | 192 | 217 | 290 | 303 | |
| I-Beam Width (mm) | 50-305 | 74-305 | 85-305 | 85-305 | 85-305 | |
| Size | a | 190 | 215 | 255 | 295 | 340 |
| b | 407 | 471 | 557 | 643 | 706 | |
| c | 295 | 325 | 410 | 490 | 520 | |
| d | 194 | 215 | 262 | 325 | 323 | |
| e | 88 | 85 | 122 | 123 | 351 | |
| G | 30 | 34 | 37 | 47 | 61 | |
| Hmin | 183 | 209 | 260 | 315 | 366 | |
Welcome to buy the newest and competitive price DAWSON DS-YTG 1-10T Low Level Hand Chain Hoist Trolley, 1000-10000kg Low Headroom Hoist Trolley from our factory. We're one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.
For further information, please contact us. Email:info@dawson-group.com
