| Polyester Flat Webbing Sling | |
 | Type -Double ply polyester webbing sling with reinforced lifting eyes Technical specifications -Wide & flat load bearing surface -Sling has reinforced eyes at both ends _Capacity from 1t to 12t -Color coded according to EN 1492-1. Characteristics -Low elongation. Norms -According to Machine Directive 2006/42/EC & EN 1492-1 -Safety Factor: 7:1 to EN 1492-1 -Safety Factor of 6:1 or 5:1 is available upon request |
 | Item | Color coded according to EN 1492-1 | Working Load Limit with 1 webbing sling | Working Load Limit with 2 webbing sling | |||||||
| Straight lift | Choked lift | β | Straight lift up to 45 | Choked lift up to 45 | Straight lift 45-60 | Choked lift 45-60 | |||||
| 0-7 | 7-45 | 45-60 | |||||||||
| 1.0 | 0.8 | 2.0 | 1.4 | 1.0 | 1.4 | 1.12 | 1.0 | 0.8 | |||
| DSWSDP-201 | WLL 1T | 1,000 | 800 | 2,000 | 1,400 | 1,000 | 1,400 | 1,120 | 1,000 | 800 | |
| DSWSDP-202 | WLL 2T | 2,000 | 1,600 | 4,000 | 2,800 | 2,000 | 2,800 | 2,240 | 2,000 | 1,600 | |
| DSWSDP-203 | WLL 3T | 3,000 | 2,400 | 6,000 | 4,200 | 3,000 | 4,200 | 3,360 | 3,000 | 2,400 | |
| DSWSDP-204 | WLL 4T | 4,000 | 3,200 | 8,000 | 5,600 | 4,000 | 5,600 | 4,480 | 4,000 | 3,200 | |
| DSWSDP-205 | WLL 5T | 5,000 | 4,000 | 10,000 | 7,000 | 5,000 | 7,000 | 5,600 | 5,000 | 4,000 | |
| DSWSDP-206 | WLL 6T | 6,000 | 4,800 | 12,000 | 8,400 | 6,000 | 8,400 | 6,720 | 6,000 | 4,800 | |
| DSWSDP-208 | WLL8T | 8,000 | 6,400 | 16,000 | 11,200 | 8,000 | 12,000 | 8,960 | 8,000 | 6,400 | |
| DSWSDP-210 | WLL10T | 10,000 | 8,000 | 20,000 | 14,000 | 10,000 | 14,000 | 11,200 | 10,000 | 8,000 | |
| DSWSDP-212 | WLL 12T | 12,000 | 9,600 | 24,000 | 16,800 | 12,000 | 16,800 | 13,440 | 12,000 | 9,600 | |
Dawson Webbing sling is produced from top quality synthetic fiber by advanced international level of weaving technology and equipment in various sewing methods . According to customer's requirement, the safety factor of sling has 4:1,5:1,6:1,7:1,8:1, its load range is from 0.2t to 100t ,Which is produced according to international standard, for color and load capacity
| S.F | 6:1 | 7:1 | 8:1 | ||||||
| WLL(kg) | Stock No | Width | M.B.S | Stock No | Width | M.B.S | Stock No | Width | M.B.S |
| 1000 | DSEE6010 | 25/38mm | 6t | DSEE7010 | 30/50mm | 7t | DSEE8010 | 50mm | 8t |
| 2000 | DSEE6020 | 50mm | 12t | DSEE7020 | 60mm | 14t | DSEE8020 | 65mm | 16t |
| 3000 | DSEE6030 | 75mm | 18t | DSEE7030 | 90mm | 21t | DSEE8030 | 95mm | 24t |
| 4000 | DSEE6040 | 100mm | 24t | DSEE7040 | 120mm | 28t | DSEE8040 | 120mm | 32t |
| 5000 | DSEE6050 | 125mm | 30t | DSEE7050 | 150mm | 35t | DSEE8050 | 150mm | 40t |
| 6000 | DSEE6060 | 150mm | 36t | DSEE7060 | 180mm | 42t | DSEE8060 | 180mm | 48t |
| 8000 | DSEE6080 | 200mm | 48t | DSEE7080 | 240mm | 56t | DSEE8080 | 240mm | 64t |
| 10000 | DSEE6100 | 250mm | 60t | DSEE7100 | 300mm | 70t | DSEE8100 | 300mm | 80t |
| 12000 | DSEE6120 | 300mm | 72t | DSEE7120 | 300mm | 84t | / | / | / |
| MEMO | JB/T8521.1 | EN1492.1 | AS1353 | ||||||
 |  |  |
 |  |  |
 |  |  |
Other sizes can be produced upon request, more information, please contact us: info@dawson-group.com
Other sizes can be produced upon request, more information, please contact us: info@dawson-group.com
